UPS- 125kW 250kW 375kW 500kW 625kW

UPS- 125kW 250kW 375kW 500kW 625kW

Category:

APEX Ultimate High-Power Industrial UPS Series

APEX Ultimate introduces professional-grade high-power UPS (Uninterruptible Power Supply) series, offering five power specifications: 125kW, 250kW, 375kW, 500kW, and 625kW. Designed specifically for industrial manufacturing, medical facilities, and critical infrastructure, this series ensures millisecond-level uninterrupted power supply for your critical loads during grid abnormalities.

Core Product Advantages:​

Extensive Power Range: Wide power coverage from 125kW to 625kW meets the power protection needs of enterprises of various scales. Whether it’s small manufacturing workshops or large workshops, you can find a matching solution.

Millisecond Switching Response: Utilizing advanced IGBT inverter technology and digital signal processing, it achieves a switching time of < 20ms, ensuring sensitive equipment remains unaffected during grid fluctuations or power outages. Particularly suitable for precision instruments and automated production lines.

Industrial-Grade Reliability: Fully modular design with redundant configuration of critical components, MTBF (Mean Time Between Failures) exceeds 200,000 hours. Employs industrial-grade components and enhanced cooling systems to ensure stable operation in harsh environments.

Intelligent Energy Management: Built-in smart battery management system monitors battery status in real-time, optimizes charging/discharging strategies, and extends battery life by over 30%. Supports remote monitoring and fault alerts, with centralized management via Web interface or mobile APP.

High-Efficiency Energy-Saving Design: Double-conversion online topology, input power factor >0.99, overall efficiency up to 96% (reaching 99% in ECO mode), significantly reducing operational energy consumption and cooling requirements.

Flexible Expansion Configuration: Modular architecture supports hot-swapping and online capacity expansion, allowing a gradual addition of power modules to meet business growth needs while protecting the initial investment.

Application Scenarios:​

  • Industrial Manufacturing: Protects automated production lines, CNC machines, and robotic systems from voltage sags and power outages
  • Critical Infrastructure: Provides a reliable power supply for traffic signals, security monitoring, and communication base stations

Technical Specification Highlights:​

  • Input voltage range: 380V/400V/415V ±20%
  • Output voltage: 380V/400V/415V, THD<3%
  • Frequency range: 50/60Hz ±10%
  • Battery configuration: Standard 120-minute backup time, expandable to several hours
  • Protection level: IP20 (indoor installation), optional IP41/IP54
  • Operating temperature: 0-40°C, optional -10-50°C wide-temperature version
  • Communication interfaces: RS232, RS485, CAN

Service Support:​

APEX Ultimate provides a 2-year whole-unit warranty and a 1-year battery warranty for each UPS. We offer professional on-site surveys, solution design, installation commissioning, and regular maintenance services to ensure systems remain in optimal condition. Through our global service network, you can access localized technical support in over 40 countries and regions.

Choosing APEX Ultimate high-power UPS is not just selecting a device, but also making a solemn commitment to business continuity. Let us provide rock-solid power protection for your critical operations, helping you maintain a competitive edge in the intense market environment.
